Sale!
$63.19
AMD introduces the latest Ryzen 2000 series processors to provide the computing power for gaming need. GIGABYTE’s 400-series motherboards perfectly fit the latest AMD Ryzen 2000 series processors’ computing performance with more features and more control. Users can enjoy the benefits brought by AMD Ryzen 2000 series processors.
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
AMD introduces the latest Ryzen 2000 series processors to provide the computing power for gaming need. GIGABYTE’s 400-series motherboards perfectly fit the latest AMD Ryzen 2000 series processors’ computing performance with more features and more control. Users can enjoy the benefits brought by AMD Ryzen 2000 series processors.
| SKU | 808931 |
|---|---|
| Supported Memory Technologies | ECC Memory Supported Non-ECC Memory Supported Extreme Memory Profile (XMP) Unbuffered Memory Supported |
| UPC | 889523014387 |
| Packaging | Retail |
| General Features | RGB Lighting 4K Resolution |
| Manufacturer Features | Support for APP Center, Support for Q-Flash, Support for Xpress Install, Smart Fan 5, AMD StoreMI technology |
| Overclocking Features | EasyTune |
| Microsoft Certifications | Windows 10 Ready Windows 7 Ready |
| Manageability | PnP 1.0a WfM 2.0 SM BIOS 2.7 ACPI 5.0 DMI 2.7 |
| BIOS | 2 x 128Mb AMI UEFI BIOS |
| North Bridge | AMD B450 |
| Socket Type | AM4 |
| SATA Express | 1 x M.2 Socket 3 M Key |
| Mfr Part# | B450 AORUS M |
| Maximum Memory Supported Per Slot | 32GB |
| Memory Type | DDR4-2133 DDR4-2400 DDR4-2667 DDR4-2933 |
| Memory Speeds Supported | DDR4 3200 O.C., 2933, 2667, 2400, 2133 |
| Memory Slots | 4 x 288pin DIMM |
| Max Memory Supported | 128GB |
| Memory Channel Support | Dual Channel |
| Video Memory | Shared Video Memory (up to 16000MB) |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| Multi-GPU Support | Quad CrossfireX 2-Way CrossFire |
| M.2 Port Type | 2242 2260 2280 22110 |
| AMD CPU Support | Ryzen |
| SATA 6Gb/s | 6 |
| Legacy Ports | 1 x PS/2 |
| LAN Ports | 1 x 10/100/1000 RJ-45 LAN |
| Audio Channels | 7.1 |
| Supported Network Technologies | Wake On Lan PXE Boot Energy Efficient Ethernet 802.3az |
| LAN Chipset | Realtek GbE LAN |
| LAN Speed | 10/100/1000Mbps |
| PCI Express 2.0 x16 | 1 |
| PCI Express 3.0 x16 | 1 |
| PCI Express x1 | 1 |
| USB 2.0 | 2 x USB 2.0 (Type-A) |
| Video Connectors | 1 x DVI-D 1 x HDMI 1.4 |
| USB 3.1 | 4 x USB 3.2 (Gen 1 Type-A) 2 x USB 3.2 (Gen 2 Type-A) |
| RAID Support | RAID 0 RAID 1 RAID 10 |
| Audio Chipset | Realtek ALC892 |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Front Speaker 1 x 3.5 mm Rear Speaker 1 x 3.5 mm Subwoofer 1 x 3.5 mm Side Speaker |
| Headers | 1 x CPU Fan Header 1 x Front Panel Header 1 x Front Audio Header 1 x TPM Header 1 x S/PDIF-Out Header 1 x Serial Port Header 1 x Parallel Port Header 2 x System Fan Header 1 x RGB Header |
| Other I/O | 1 x Clearing CMOS Jumper |
| Power Connectors | 1 x 24-pin ATX Connector 1 x 8-pin +12 V Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Depth | 9.61 in. (244.00 mm) |
| Width | 9.61 in. (244.00 mm) |
| Form Factor | microATX |
| Parts | 3 Years |
| Labor | 3 Years |
| What's in the Box | Motherboard, Cables, Connectors, Product Manual |
