Original price was: $511.99.$96.99Current price is: $96.99.
Showcasing a state-of-the-art design, excellent functionality, an impressive thermal design, next generation connectivity, a Hi-Fi level audio system, and AORUS aesthetics, the flagship Z590 AORUS XTREME motherboard dominates the competition.
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
Showcasing a state-of-the-art design, excellent functionality, an impressive thermal design, next generation connectivity, a Hi-Fi level audio system, and AORUS aesthetics, the flagship Z590 AORUS XTREME motherboard dominates the competition.
| SKU | 258855 |
|---|---|
| WiFi Support | Onboard WiFi |
| Packaging | Retail |
| Manageability | PnP 1.0a WfM 2.0 ACPI 5.0 DMI 2.7 |
| BIOS | 2 x 256Mb UEFI AMI BIOS Flash ROM |
| North Bridge | Intel Z590 |
| Socket Type | LGA 1200 |
| Intel CPU Support | Core i7 Core i5 Core i3 Celeron Pentium Core i9 |
| Maximum Memory Supported Per Slot | 32GB |
| Memory Type | DDR4-2133 DDR4-2400 DDR4-2666 DDR4-2933 DDR4-3200 DDR4-2800 DDR4-3000 |
| Memory Slots | 4 x 288pin DIMM |
| Max Memory Supported | 128GB |
| Memory Speeds Supported | 5400 (O.C) / DDR4 5333(O.C.) / DDR4 5133(O.C.) / DDR4 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz |
| Memory Channel Support | Dual Channel |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| Multi-GPU Support | 2-Way CrossFire |
| M.2 Port Type | 2242 2260 2280 22110 |
| SATA Express | 3 x M.2 Socket 3 M Key |
| SATA 6Gb/s | 6 |
| RAID Support | RAID 0 RAID 1 RAID 5 RAID 10 |
| Audio Chipset | Realtek ALC1220-VB codec + ESS ES9018K2M DAC + TI OPA1622 operational amplifier |
| Audio Channels | 7.1 |
| UPC | 889523027172 |
| Mfr Part# | Z590AORUSXTREME |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Rear Speaker 1 x 3.5 mm Subwoofer 1 x 3.5 mm Line-Out |
| Digital Audio | 1 x Optical |
| Wireless LAN Chipset | Intel Wi-Fi 6E AX210 |
| Wireless Technology | 802.11b 802.11g 802.11a WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) Bluetooth v5.2 |
| PCI Express 4.0 x16 | 2 |
| PCI Express 3.0 x16 | 1 |
| Specialty Ports | 2 x WiFi Antenna Ports |
| Thunderbolt Ports | 2 x Thunderbolt 4 |
| USB 3.1 | 8 x USB 3.2 (Gen 2 Type-A) |
| Video Connectors | 1 x HDMI 1.4 |
| LAN Ports | 1 x 10/100/1000/2500 RJ-45 LAN 1 x 100/1000/2500/5000/10000Mbps |
| LAN 2 Chipset | Intel 2.5GbE LAN chip |
| LAN Chipset | Aquantia 10GbE LAN chip |
| Headers | 1 x CPU Fan Header 1 x Water Pump Header 6 x System Fan Header |
| USB | 1 x USB 2.0 Header (2 Ports) 1 x USB 3.2 Gen 1 Type-A Header (2 Ports) 1 x USB 3.2 Gen 2×2 Type-C Header (1 Port) |
| Power Connectors | 1 x 24-pin ATX Connector 2 x 8-pin +12 V Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Depth | 12.00 in. (305.00 mm) |
| Width | 10.63 in. (270.00 mm) |
| Form Factor | ATX |
| Parts | 3 Years |
| Labor | 3 Years |
| LAN Speed | 100/1000/2500/5000/10000Mbps |
| What's in the Box | Motherboard, USB Flash Drive w/ Drivers, Manual, Install Drive, 6x SATA Cables, Antennas, RGB LED Extension Cables, Front Panel Extension Cable, Front USB Extension Cable, ESSential USB DAC, Noise Detection Cable, 2x Thermistor Cables, G Connector, 2x Velcro Cable Ties, M.2 Screws, AORUS Gen4 AIC Adaptor |
