Sale!
$95.99
The MEG series seeks to transcend current gaming products, the flagship model designed to push the limits of what an extreme gaming series can be. Combining the strengths of our existing arsenal with new innovative technology; this results in significant improvements in operational and gaming efficiency. With the MEG series, take complete control of performance and personalization with the ultimate gaming series for enthusiasts who want it all.
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
The MEG series seeks to transcend current gaming products, the flagship model designed to push the limits of what an extreme gaming series can be. Combining the strengths of our existing arsenal with new innovative technology; this results in significant improvements in operational and gaming efficiency. With the MEG series, take complete control of performance and personalization with the ultimate gaming series for enthusiasts who want it all.
| SKU | 112383 |
|---|---|
| LAN 2 Chipset | Intel I219V |
| Packaging | Retail |
| North Bridge | Intel Z490 |
| Socket Type | LGA 1200 |
| Intel CPU Support | Core i7 Core i5 Core i3 Celeron Pentium Core i9 |
| Maximum Memory Supported Per Slot | 32GB |
| Memory Type | DDR4-2133 DDR4-2666 DDR4-2933 |
| Memory Slots | 4 x 288pin DIMM |
| Memory Channel Support | Dual Channel |
| Multi-GPU Support | 2-Way SLI 2-Way CrossFire 3-Way CrossFire |
| Max Memory Supported | 128GB |
| SATA Express | 3 x M.2 Socket 3 M Key |
| M.2 Port Type | 2242 2260 2280 22110 |
| SATA 6Gb/s | 6 |
| RAID Support | RAID 0 RAID 1 RAID 5 RAID 10 |
| Audio Chipset | Realtek ALC1220 Codec + ESS SABRE9018Q2C combo DAC |
| Audio Channels | 7.1 |
| WiFi Support | Onboard WiFi |
| LAN Chipset | Realtek 8125B |
| UPC | 824142199053 |
| Mfr Part# | MEG Z490 ACE |
| Digital Audio | 1 x Optical |
| Headers | 1 x CPU Fan Header 6 x System Fan Header |
| PCI Express 3.0 x16 | 3 |
| PCI Express x1 | 2 |
| Specialty Ports | 2 x WiFi Antenna Ports |
| USB 2.0 | 2 x USB 2.0 (Type-A) |
| USB 3.1 | 1 x USB 3.2 (Gen 2×2 Type-C) 2 x USB 3.2 (Gen 1 Type-A) 3 x USB 3.2 (Gen 2 Type-A) |
| LAN Ports | 1 x 10/100/1000 RJ-45 LAN 1 x 10/100/1000/2500 RJ-45 LAN |
| Legacy Ports | 1 x PS/2 |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Line-Out |
| Wireless LAN Chipset | Intel AX201 |
| LAN Speed | 10/100/1000/2500Mbps |
| USB | 2 x USB 2.0 Headers (2 Ports) 1 x USB 3.2 Gen 1 Type-A Header (2 Ports) 1 x USB 3.2 Gen 2 Type-A Header (1 Port) |
| Power Connectors | 1 x 24-pin ATX Connector 2 x 8-pin +12 V Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Width | 9.61 in. (244.00 mm) |
| Depth | 12.00 in. (305.00 mm) |
| Form Factor | ATX |
| Parts | 3 Years |
| Labor | 3 Years |
| Wireless Technology | 802.11b 802.11g 802.11a WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) Bluetooth v5.1 |
| What's in the Box | Motherboard, Manual, Install Guide, Driver Disc, SATA Cables, Antenna, Case Badge, SATA Cable Stickers, Registration Card, M.2 Screws |
