$97.99
Supports AMD AM4 Socket Ryzen 2000 and 3000 Series processors Power Phase Design Supports DDR4 4400 (OC) PCIe 4.0 x16, 1 PCIe 4.0 x1, 1 M.2(Key E) For WiFi AMD Quad CrossFireX and CrossFireX Graphics Output Options: HDMI, DisplayPort 7.1 CH HD Audio (Realtek ALC1200 Audio Codec), ELNA Audio Caps SATA3, 1 Hyper M.2 (PCIe Gen4 x4 & SATA3), Hyper M.2 (PCIe Gen4 x4) USB 3.2 Gen2 (Rear Type A C), 8 USB 3.2 Gen1 (2 Front, 6 Rear) Intel Gigabit LAN ASRock Polychrome SYNC.
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
Supports AMD AM4 Socket Ryzen 2000 and 3000 Series processors Power Phase Design Supports DDR4 4400 (OC) PCIe 4.0 x16, 1 PCIe 4.0 x1, 1 M.2(Key E) For WiFi AMD Quad CrossFireX and CrossFireX Graphics Output Options: HDMI, DisplayPort 7.1 CH HD Audio (Realtek ALC1200 Audio Codec), ELNA Audio Caps SATA3, 1 Hyper M.2 (PCIe Gen4 x4 & SATA3), Hyper M.2 (PCIe Gen4 x4) USB 3.2 Gen2 (Rear Type A C), 8 USB 3.2 Gen1 (2 Front, 6 Rear) Intel Gigabit LAN ASRock Polychrome SYNC.
| SKU | 957159 |
|---|---|
| RAID Support | RAID 0 RAID 1 RAID 10 |
| Packaging | Retail |
| Microsoft Certifications | Windows 10 Ready |
| Manageability | ACPI 5.1 |
| BIOS | 256Mb AMI UEFI Bios |
| North Bridge | AMD X570 |
| Socket Type | AM4 |
| AMD CPU Support | Ryzen |
| Supported Memory Technologies | ECC Memory Supported Non-ECC Memory Supported Extreme Memory Profile (XMP) |
| Memory Type | DDR4-2133 DDR4-2400 DDR4-2667 DDR4-2933 DDR4-3200 |
| Memory Speeds Supported | 4666+(O.C.), 4400(O.C.), 4300(O.C.), 4266(O.C.), 4200(O.C.), 4133(O.C.), 3466(O.C.), 3200, 2933, 2667, 2400, 2133 |
| Maximum Memory Supported Per Slot | 32GB |
| Memory Slots | 4 x 288pin DIMM |
| Max Memory Supported | 128GB |
| Memory Channel Support | Dual Channel |
| Video Memory | Shared Video Memory (up to 16GB) |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| Multi-GPU Support | 2-Way CrossFireX 3-Way CrossfireX |
| M.2 Port Type | 2242 2260 2280 22110 |
| SATA Express | 2 x M.2 Socket 3 M Key 1 x M.2 Socket 3 E Key |
| SATA 6Gb/s | 8 |
| UPC | 4717677338881 |
| Mfr Part# | MBX570PHANGAM4 |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Rear Speaker 1 x 3.5 mm Subwoofer |
| Digital Audio | 1 x Optical |
| LAN Speed | 10/100/1000Mbps |
| PCI Express 4.0 x16 | 1 |
| PCI Express 3.0 x16 | 1 |
| PCI Express x1 | 2 |
| Specialty Ports | 2 x WiFi Antenna Ports |
| USB 3.1 | 2 x USB 3.2 (Gen 2 Type-A) 6 x USB 3.2 (Gen 1 Type-A) |
| Video Connectors | 1 x DisplayPort 1.2 1 x HDMI 1.4 |
| Legacy Ports | 1 x PS/2 |
| LAN Ports | 1 x 10/100/1000 RJ-45 LAN |
| Audio Channels | 7.1 |
| Audio Chipset | Realtek ALC1220 |
| Headers | 1 x CPU Fan Header 1 x Water Pump Header 1 x RGB Header |
| USB | 2 x USB 2.0 Headers (4 Ports) 1 x USB 3.2 Gen 1 Type-A Header (2 Ports) |
| Power Connectors | 1 x 24-pin ATX Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Depth | 9.61 in. (244.00 mm) |
| Width | 12.00 in. (304.80 mm) |
| Form Factor | ATX |
| Parts | 3 Years |
| Labor | 3 Years |
| LAN Chipset | Intel I211AT |
| What's in the Box | Board, 4x SATA Cables, SLI Bridge, Screwdriver, 3x M.2 Screws, 2x M.2 Standoffs |
