Sale!
$98.99
Inspired from architectural design, with Lightning Gen 4 PCIe and M.2 solution, Frozr Heatsink, Core Boost, DDR4 Boost, Audio Boost 4, USB 3.2 Gen 2 connector
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
Inspired from architectural design, with Lightning Gen 4 PCIe and M.2 solution, Frozr Heatsink, Core Boost, DDR4 Boost, Audio Boost 4, USB 3.2 Gen 2 connector
| SKU | 958629 |
|---|---|
| Memory Speeds Supported | 4400 O.C., 4266 O.C., 4133 O.C., 4000 O.C., 3866 O.C., 3733 O.C., 3600 O.C., 3466 O.C., 3200, 3000, 2800, 2666, 2400, 2133 |
| UPC | 824142189627 |
| Packaging | Retail |
| Microsoft Certifications | Windows 10 Ready |
| North Bridge | AMD X570 |
| Socket Type | AM4 |
| AMD CPU Support | Ryzen |
| Supported Memory Technologies | ECC Memory Supported Non-ECC Memory Supported Extreme Memory Profile (XMP) |
| Maximum Memory Supported Per Slot | 32GB |
| RAID Support | RAID 0 RAID 1 RAID 10 |
| Mfr Part# | X570-A PRO |
| Memory Slots | 4 x 288pin DIMM |
| Max Memory Supported | 128GB |
| Memory Channel Support | Dual Channel |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| Multi-GPU Support | 2-Way CrossFire |
| M.2 Port | Socket 3 M Key (x2) |
| M.2 Port Type | 2242 2260 2280 22110 |
| SATA Express | 2 x M.2 Socket 3 M Key |
| SATA 6Gb/s | 6 |
| Memory Type | DDR4-2133 DDR4-2400 DDR4-2667 DDR4-1866 DDR4-2933 DDR4-3200 DDR4-2800 DDR4-3000 |
| Audio Chipset | Realtek ALC1220 |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Rear Speaker 1 x 3.5 mm Subwoofer |
| Digital Audio | 1 x Optical |
| LAN Speed | 10/100/1000Mbps |
| PCI Express 4.0 x16 | 2 |
| PCI Express x1 | 3 |
| USB 2.0 | 2 x USB 2.0 (Type-A) |
| USB 3.1 | 4 x USB 3.2 (Gen 1 Type-A) 1 x USB 3.2 (Gen 2 Type-C) 1 x USB 3.2 (Gen 2 Type-A) |
| Video Connectors | 1 x HDMI 1.4 |
| Legacy Ports | 1 x PS/2 |
| LAN Ports | 1 x 10/100/1000 RJ-45 LAN |
| Audio Channels | 7.1 |
| LAN Chipset | Realtek 8111H |
| Headers | 1 x CPU Fan Header |
| USB | 2 x USB 2.0 Headers (4 Ports) 2 x USB 3.2 Gen 1 Type-A Headers (4 Ports) |
| Power Connectors | 1 x 24-pin ATX Connector 1 x 8-pin +12 V Connector 1 x 4-pin +12 V Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Depth | 9.60 in. (243.84 mm) |
| Width | 12.00 in. (304.80 mm) |
| Form Factor | ATX |
| Parts | 1 Year |
| Labor | 1 Year |
| What's in the Box | Motherboard, SATA Cables, M.2 Screws, Case Badge, Registration Card, Driver Disc, Install Guide |
Be the first to review “MSI X570-A Pro AM4 ATX AMD Motherboard”
