Sale!
$98.99
Supports 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics Desktop Processors for AM4 socket Supports DDR4 Memory Lightning Fast Game experience: PCIe 4.0: Lightning Gen4 x4 M.2 with M.2 Shield Frozr accessory: StoreMI: AMD Turbo USB 3.2 GEN2 Frozr Heatsink Design: Designed with the patented fan and double ball bearings to provide the best performance for enthusiast gamers and prosumers. Set Core Power Free: Extended Heatsink Design: Core Boost: Digital PWM IC: 8 4 pin CPU power connector: Game Boost: DDR4 Boost MYSTIC LIGHT: 16.8 million colors / 29 effects controlled in one click. MYSTIC LIGHT EXTENSION supports both RGB and RAINBOW LED strip. AUDIO BOOST 4: Reward your ears with studio grade sound quality for the most immersive gaming experience Dragon Center: A brand new software which integrates all MSI tools like GAME MODE: VOICE BOOST: LIVE UPDATE with a user-friendly user interface.
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
Supports 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics Desktop Processors for AM4 socket Supports DDR4 Memory Lightning Fast Game experience: PCIe 4.0: Lightning Gen4 x4 M.2 with M.2 Shield Frozr accessory: StoreMI: AMD Turbo USB 3.2 GEN2 Frozr Heatsink Design: Designed with the patented fan and double ball bearings to provide the best performance for enthusiast gamers and prosumers. Set Core Power Free: Extended Heatsink Design: Core Boost: Digital PWM IC: 8 4 pin CPU power connector: Game Boost: DDR4 Boost MYSTIC LIGHT: 16.8 million colors / 29 effects controlled in one click. MYSTIC LIGHT EXTENSION supports both RGB and RAINBOW LED strip. AUDIO BOOST 4: Reward your ears with studio grade sound quality for the most immersive gaming experience Dragon Center: A brand new software which integrates all MSI tools like GAME MODE: VOICE BOOST: LIVE UPDATE with a user-friendly user interface.
| SKU | 957100 |
|---|---|
| Memory Type | DDR4-2133 DDR4-2400 DDR4-2666 DDR4-1866 |
| UPC | 824142189535 |
| Packaging | Retail |
| Microsoft Certifications | Windows 10 Ready |
| North Bridge | AMD X570 |
| Socket Type | AM4 |
| AMD CPU Support | Ryzen |
| Supported Memory Technologies | ECC Memory Supported Non-ECC Memory Supported Extreme Memory Profile (XMP) |
| Audio Channels | 7.1 |
| Mfr Part# | MPGX570GAMPLUS |
| Memory Slots | 4 x 288pin DIMM |
| Max Memory Supported | 128GB |
| Memory Channel Support | Dual Channel |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| Multi-GPU Support | 2-Way CrossFire |
| M.2 Port Type | 2242 2260 2280 22110 |
| SATA 6Gb/s | 6 |
| RAID Support | RAID 0 RAID 1 RAID 10 |
| Maximum Memory Supported Per Slot | 32GB |
| LAN Chipset | Realtek 8111H |
| Digital Audio | 1 x Optical |
| Headers | 1 x CPU Fan Header 4 x System Fan Header 1 x Water Pump Header |
| PCI Express x1 | 3 |
| Legacy Ports | 1 x PS/2 |
| LAN Ports | 1 x 10/100/1000 RJ-45 LAN |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Rear Speaker 1 x 3.5 mm Subwoofer |
| USB 2.0 | 2 x USB 2.0 (Type-A) |
| USB 3.1 | 4 x USB 3.2 (Gen 1 Type-A) 1 x USB 3.2 (Gen 2 Type-C) 1 x USB 3.2 (Gen 2 Type-A) |
| Video Connectors | 1 x HDMI 1.4 |
| LAN Speed | 10/100/1000Mbps |
| PCI Express 4.0 x16 | 2 |
| USB | 2 x USB 2.0 Headers (4 Ports) 2 x USB 3.2 Gen 1 Type-A Headers (4 Ports) |
| Power Connectors | 1 x 24-pin ATX Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Depth | 9.61 in. (244.00 mm) |
| Width | 12.00 in. (304.80 mm) |
| Form Factor | ATX |
| Parts | 1 Year |
| Labor | 1 Year |
| What's in the Box | Board, Manual, Install Guide, Case Badge, M.2 Shield, Driver DVD, 2x SATA Cables, IO Shield |
