$91.99
With years of experience, MSI is no stranger to building high-performance motherboards. Our R&D and engineering teams have reviewed countless designs, evaluated a wide selection of high quality components, and developed products for reliability even under extreme conditions.
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
With years of experience, MSI is no stranger to building high-performance motherboards. Our R&D and engineering teams have reviewed countless designs, evaluated a wide selection of high quality components, and developed products for reliability even under extreme conditions.
| SKU | 353037 |
|---|---|
| Audio Channels | 7.1 |
| Packaging | Retail |
| Microsoft Certifications | Windows 11 Ready |
| North Bridge | Intel Z690 |
| Socket Type | LGA 1700 |
| Intel CPU Support | Core i7 Core i5 Core i3 Celeron Pentium Core i9 |
| Supported Memory Technologies | Non-ECC Memory Supported Extreme Memory Profile (XMP) |
| Maximum Memory Supported Per Slot | 32GB |
| Memory Speeds Supported | 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6133(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800 |
| Memory Slots | 2 x 288pin DIMM |
| Memory Type | DDR5-4800 |
| Max Memory Supported | 64GB |
| Memory Channel Support | Dual Channel |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| M.2 Port Type | 2280 |
| SATA Express | 3 x M.2 Socket 3 M Key |
| SATA 6Gb/s | 4 |
| RAID Support | RAID 0 RAID 1 RAID 5 RAID 10 |
| Audio Chipset | Realtek ALC4080 |
| UPC | 824142270325 |
| Mfr Part# | MEG Z690I UNIFY |
| Video Connectors | 1 x HDMI 2.1 1 x DisplayPort 1.4 2 x Mini-DisplayPort Input |
| Headers | 1 x CPU Fan Header 1 x Water Pump Header 1 x System Fan Header |
| Wireless LAN Chipset | Intel WiFi 6E |
| Wireless Technology | 802.11b 802.11g 802.11a WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) Bluetooth v5.2 |
| PCI Express 5.0 x16 | 1 |
| LAN Ports | 1 x 10/100/1000/2500 RJ-45 LAN |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Line-Out |
| Specialty Ports | 2 x WiFi Antenna Ports |
| Thunderbolt Ports | 2 x Thunderbolt 4 |
| USB 3.1 | 4 x USB 3.2 (Gen 1 Type-A) 2 x USB 3.2 (Gen 2 Type-A) |
| LAN Chipset | Intel I225V |
| WiFi Support | V-M.2 Slot |
| USB | 1 x USB 2.0 Header (2 Ports) 1 x USB 3.2 Gen 1 Type-A Header (2 Ports) 1 x USB 3.2 Gen 2×2 Type-C Header (1 Port) |
| Power Connectors | 1 x 24-pin ATX Connector 1 x 8-pin +12 V Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Depth | 6.70 in. (170.00 mm) |
| Width | 6.70 in. (170.00 mm) |
| Form Factor | Mini-ITX |
| Parts | 3 Years |
| Labor | 3 Years |
| LAN Speed | 10/100/1000/2500Mbps |
| What's in the Box | Motherboard, Install Guide, USB Drive w/ Drivers, SATA Cable, JRAINBOW Cable, DP to Mini-DP Cable, Front Panel Cable, Antenna, Case Badge, M.2 Screws, MEG Sticker, SATA Cable Sticker, Registration Card, Screwdriver Set, Small Brush |
