$88.79
AMD introduces the latest Ryzen 2000 series processors to provide the computing power for gaming need. GIGABYTE’s 400-series motherboards perfectly fit the latest AMD Ryzen 2000 series processors’ computing performance with more features and more control. Users can enjoy the benefits brought by AMD Ryzen 2000 series processors.
- Protect Your Wallet with Safe Payments
- Online assistance, always at your service.
- Safe Shopping Guaranteed
- Best price, safe shopping guarantee
AMD introduces the latest Ryzen 2000 series processors to provide the computing power for gaming need. GIGABYTE’s 400-series motherboards perfectly fit the latest AMD Ryzen 2000 series processors’ computing performance with more features and more control. Users can enjoy the benefits brought by AMD Ryzen 2000 series processors.
| SKU | 808923 |
|---|---|
| Supported Memory Technologies | ECC Memory Supported Non-ECC Memory Supported Extreme Memory Profile (XMP) Unbuffered Memory Supported |
| UPC | 889523014349 |
| Packaging | Retail |
| General Features | RGB Lighting 4K Resolution Dual Band 802.11ac WiFi Bluetooth v4.2 |
| Manufacturer Features | Support for APP Center, Support for Q-Flash, Support for Xpress Install, Smart Fan 5 |
| Overclocking Features | EasyTune |
| Microsoft Certifications | Windows 10 Ready Windows 7 Ready |
| Manageability | PnP 1.0a WfM 2.0 SM BIOS 2.7 ACPI 5.0 DMI 2.7 |
| BIOS | 2 x 128Mb AMI UEFI BIOS |
| North Bridge | AMD B450 |
| Socket Type | AM4 |
| RAID Support | RAID 0 RAID 1 RAID 10 |
| Mfr Part# | B450 AORUS PRO WIFI |
| Maximum Memory Supported Per Slot | 32GB |
| Memory Type | DDR4-2133 DDR4-2400 DDR4-2667 DDR4-2933 |
| Memory Speeds Supported | DDR4 3600 O.C., 3466 O.C., 3200 O.C., 2933, 2667, 2400, 2133 |
| Memory Slots | 4 x 288pin DIMM |
| Max Memory Supported | 128GB |
| Memory Channel Support | Dual Channel |
| Onboard Graphic Chipset | Requires CPU with Integrated Graphics |
| Multi-GPU Support | Quad CrossfireX 2-Way CrossFire |
| M.2 Port Type | 2242 2260 2280 22110 |
| SATA Express | 2 x M.2 Socket 3 M Key |
| SATA 6Gb/s | 6 |
| AMD CPU Support | Ryzen |
| Audio Chipset | Realtek ALC1220-VB |
| LAN Ports | 1 x 10/100/1000 RJ-45 LAN |
| Audio Ports | 1 x 3.5 mm Microphone 1 x 3.5 mm Line-In 1 x 3.5 mm Front Speaker 1 x 3.5 mm Rear Speaker 1 x 3.5 mm Subwoofer |
| Supported Network Technologies | Wake On Lan PXE Boot Energy Efficient Ethernet 802.3az Supports Dual Band Frequency 2.4/5 GHz |
| LAN Chipset | Intel GbE Lan |
| LAN Speed | 10/100/1000Mbps |
| Wireless Technology | 802.11b 802.11g 802.11a WiFi 4 (802.11n) WiFi 5 (802.11ac) |
| PCI Express 2.0 x16 | 2 |
| PCI Express 3.0 x16 | 1 |
| PCI Express x1 | 1 |
| Specialty Ports | 1 x USB PowerShare |
| Video Connectors | 1 x DVI-D 1 x HDMI 1.4 (In) |
| USB 3.1 | 4 x USB 3.2 (Gen 1 Type-A) 1 x USB 3.2 (Gen 2 Type-C) 1 x USB 3.2 (Gen 2 Type-A) |
| Audio Channels | 7.1 |
| WiFi Support | Onboard WiFi |
| Digital Audio | 1 x Optical |
| Headers | 1 x CPU Fan Header 1 x Water Pump Header 1 x Front Panel Header 1 x Front Audio Header 1 x TPM Header 1 x S/PDIF-Out Header 1 x Water Cooling Fan Header 2 x System Fan Header 1 x RGB Header |
| USB | 2 x USB 2.0 Headers (4 Ports) 1 x USB 3.2 Gen 1 Type-A Header (2 Ports) |
| Other I/O | 1 x Clearing CMOS Jumper |
| Power Connectors | 1 x 24-pin ATX Connector 1 x 8-pin +12 V Connector |
| ATX Connector | 24-pin ATX Power Connector |
| Depth | 9.61 in. (244.00 mm) |
| Width | 12.00 in. (304.80 mm) |
| Form Factor | ATX |
| Parts | 3 Years |
| Labor | 3 Years |
| What's in the Box | Motherboard, Cables, Connectors, Product Manual |
